Diamond Audio DMD693 | 6x9 Inch 140W 4 Ohm 3-Way Coaxial Speakers (Pair)

Diamond Audio DMD693 | 6x9 Inch 140W 4 Ohm 3-Way Coaxial Speakers (Pair)

Introducing the DMD Series Speakers from Diamond Audio – the perfect entry-level choice for those seeking economical value and reliable performance. Achieving significant performance improvements through continuous R&D, the DMD Series speakers incorporate chemically treated voice coils and cross-flow design basket frames for superior thermal heat dissipation.

Engineered for optimal value, the DMD Series speakers feature a higher-density NBR half-roll surround to ensure greater linear performance. The Klippel® DA optimized motor and suspension symmetry guarantee that DMD Series speakers deliver tight and balanced musical reproduction, enhancing any car audio system.

Experience the exceptional quality and reliability of the DMD Series Speakers. Upgrade your audio system today and enjoy the perfect blend of performance and value with Diamond Audio's DMD Series.

Specs:

• MAX Power Handling: 140W

• RMS Power Handling: 70W

• Impedance: 4 Ohm

• Frequency Range: 60Hz - 20KHz

• Sensitivity: 86dB

• Total Diameter: 9.20" x 6.40" (233.9 x 162.8mm)

• Mounting Diameter: 8.46" x 5.79" (215 x 147.1mm)

• Mounting Depth: 2.75" (70.0mm)

• Magnet Diameter: 4.19" (106.4mm)

• Screw Hole Diameter: 6.58" x 4.71" (167.2 x 119.7mm)

Features:

• High-strength ABS injection molded frame with integral terminals

• 13mm PEI dome and 20mm silk dome tweeters

• Polypropylene cone with reinforced stamped pattern

• FEA optimized high-power ferrite motor

• Klippel® DA optimized motor and suspension symmetry

Please feel free to send us a message if you have any questions about this item or other items for sale!
