American Bass XR 10 Package | 10" 2000W D2 Subwoofer & Orion CBA4500.1D Amplifier

Sub & Amp Package Deal

(1) American Bass XR 10 Inch 2000W DVC 2 Ohm Subwoofer | XR10D2

(1) Orion Cobalt 4500W Max Monoblock Subwoofer Amplifier | CBA4500.1D

*This setup is intended to run at 1 Ohm

Get ready to experience a whole new level of bass with American Bass’ XR Series Subwoofer! If you’re serious about sound, this is the way to go. Unlike other subwoofers, The XR is equipped with newly re-designed terminals that have been conveniently positioned on one side, making installation faster and easier than ever. Just plug it in, turn up the volume and get ready to shake the ground beneath your feet!

The XR Series Subwoofer has no equal with its fiberglass reinforced cone, cast frame and stitched rubber surround. No matter what type of music you love, you can be sure that every note will be heard loud and clear for an unforgettable listening experience. So don’t wait any longer – get American Bass’ XR Series Subwoofer now for mind-blowing sound quality and bass so low you can feel it in your gut!

Also Known As: XR-10D2 / XR-10-D2 / XR10-D2 / XR1022 / XR-1022

Subwoofer Details:

• MAX Power Handling: 2000W
• RMS Power Handing: 1000W
• Impedance: DVC 2 Ohm
• Sensitivity: 88 dB
• Mounting Diameter: 9.2"
• Mounting Depth: 7.08"
• Weight: 30 lbs.
• 3.0" Diameter High-Temp 4-Layer Voice Coil
• 200oz. Double Stacked Magnet Structure
• Black Power Coated Diecast Aluminum Basket
• Stitched Rubber Surround
• Woven Fiberglass Reinforced Cone
• PVC Gasket Ring & Magnet Boot
• Chrome Push Terminals
• Recommended Ported Box Size: 1.25 - 1.5 Cubic Feet
• Owner's Manual / Spec Sheet

Amplifier Details:

• 4500W Peak Rating
• 1200W RMS X 1 @ 1 Ohm
• 650W RMS X 1 @ 2 Ohms
• 400W RMS X 1 @ 4 Ohms
• Frequency Response: 10Hz - 250Hz
• Subsonic: 15 - 50Hz
• Low Pass Crossover Continuously Variable: 40 - 250Hz
• Supply Voltage: 10 - 16V
• Input Impedance: 22k Ohm
• Signal to Noise Ratio: >90 dB
• Phase Shift: 0/180 Degrees
• Variable Bass Boost: 0 - 12dB
• Variable Input Level Control: 0.2V - 6.0V
• Fuse Rating: 105A (3 x 35A ATC)
• Positive Terminals: 1 x 4 AWG
• Negative Terminals: 1 x 4 AWG
• Remote Turn-On Signal: 10 AWG
• Speaker Output Terminals: 10 AWG
• Dimensions: 12.56" x 7.09" x 2.13"
• Weight (Approx.): 6 lbs.
• All MOSFET Power Supply & Output Stage
• Heavy Gauge / High Current Custom Power and Speaker Terminals
• 1-Ohm Stable
• Remote Gain Controller Included
• RCA Out Throughput
• 12dB Octave Low-Pass Filter
• Electronic Crossover Network
• Bass Boost Circuit
• Intelligent Power and Protection LED Indicator
• Soft Turn-on/Turn-off
• Turn-On Delay
• Fault and Protection Monitoring
• 4-Way Protection: Thermal, DC offset, Short Protection, Under & Over Voltage
